new mode wall mounted Industrial computer IPC server chassis for M-ATX MB

Module

T430F  Industrial Case

Product Feature:

T430F  Was one kind of standard wall mounted  industrial Case  with com Indicator and USB connector.

;Meanwhile, Our products are widely applied in different sectors including industrial automation, communication, electricity, network safety, intelligent transportation, video surveillance, medical care, military industry/aerospace industry, self-service terminal, date storage, digital signage, car-mounted computer and 3C application.

Technical Parameters:

Dimensions

320(W)*310(D)*162.6(H)mm

Main Board

M-ATX:9.6*9.6"(245*245mm)

Hard Disk

One 3.5-inch Hard Disk or2*2.5 HDD

CD-ROM

No

Power

 1U flex PSU

Fan

One 12025 fan

Expansion Slot

Four Full  High and Straight Slots 8*com connector ,8*USB 2.0 connector

Panel Setting

 One Power switch with Indicator  One HDD Indicator

Case Material

SGCC

Material Thickness

1.2MM

G.W/N.W

7.278KGS/4.82KGS

Carton Size
