19 inch 2u short server case with fan 3*3.5 inch HDD Strong scalability support the front PSU position

Module

K245F Industrial Case

Product Feature:

K245F is a kind of standard 19" processing industry Case with the height of 2U by applying high-quality Ma Steel flowers-free zinc plating. Featuring novel structural design, it is solid, compact and reasonable in design and easy for installation and operation. Meanwhile, it can support three 3.5-inch hard disks or two 3.5-inch & one 2.5-inch hard disk. Two 8025 cooling fans are applied to guarantee excellent heat dissipation and interior micro-positive pressure and prevent any dust from penetration. In addition, by virtue of its strong ability in enduring electromagnetic interference, resisting shock and vibration, excellent cooling system and dust-prevention system, it’s an ideal product for telecommunications, electric power,securities, CTI sectors and servers.

Technical Parameters:

Dimensions

482(W)*450(D)* 89 mm(H)

Main Board

12"* 9.6"(305*245MM)

Hard Disk

Three 3.5-inch Hard Disks or Two 3.5-inch & One 2.5-inch Hard Disk

CD-ROM

None

Power

ATX PSU

Fan

Two 8025 Fans

Expansion Slot

 Four Half High and Straight Slots and Three Full High and Straight Slots

Panel Setting

Two USB2.0; One Power Switch; One Restart Switch; One Power Indicator; One HD Indicator

Case Material

Ma Steel flowers-free zinc plating

Material Thickness

1.2MM

Delivery time

1 Week for sample ,2 Weeks for mass goods

Payment Terms

30%TT Prepay 70%TT before shipment
