Module |
R1528L Industrial Case |
|
Dimensions |
482(W)*280(D)*67.5 mm(H) |
|
Main Board |
7"*7"(170*170MM) |
|
Hard Disk |
Two 3.5-inch HD or Two 2.5-inch Hard Disks |
|
CD-ROM |
None |
|
Power Supply |
FLEX PSU |
|
Fan |
Two 6020 Fans |
|
Expansion Slot |
Two Full High and Straight Slot (Riser Card is needed/Optional) |
|
Panel Setting |
Two USB2.0; One Power Switch; One Restart Switch; One Power Indicator; One HD Indicator |
|
Case Material |
Ma Steel flowers-free zinc plating |
|
Material Thickness |
1.2MM |
|
Delivery time |
1 Week for sample ,2 Weeks for mass goods |
|
Payment Terms |
30%TT Prepay 70%TT before shipment |
• Dimensions(mm)：482(W）*280(D）*67.5 mm（H）
• Main Board：7"*7"(170*170MM)
• Hard Disk：2*3.5" HDD and 2*2.5" HDD support
• CD-ROM：No
• Power：FLEX PSU
• Fan：2*6020 cooling fan
• Expansion Slot：wo Full High and Straight Slot (Riser Card is needed/Optional)
• Panel Setting： Two USB2.0; One Power Switch; One Restart Switch; One Power Indicator; One HD Indicator
• Case Material：SGCC
• Material Thickness：1.2MM
• Packaging size：44*42*17.5CM(0.032CBM)
• Gross weight：5.2KG
• N.W：4.3KG
• Container loading quantity：20＂:875 40＂: 1800 40HQ＂：2125
