6gpu 8gpu 13GPU Open Air fram Mining Case Server Miner Case Mining Rig Case with Fan

Module

6W Miner Case

Product Feature:

•6W Miner Case are standard 6U IPC case with 430(W)*470(D)*267 mm(H) Dimensions

•Holes for cooling cover the side and top panel of case,The brackets for fixing Graphics can move flexibly

•Graphics can be fixed in the case with special brackets,Support 330mm Graphic size

•Support one 3.5" desktop hard disk or One 2.5" solid state disk

•Support Double ATX Power

•Provide OEM/ODM Service with Free Design

Technical Parameters:

Dimensions

430(W)*700(D)*267 mm(H)

Main Board

12"*9.6"(305*245mm)

Hard Disk

One 3.5-inch Hard Disk or One 2.5-inch Hard Disk

CD-ROM

None

Power

Double ATX PSU

Fan

Three 12cm Fans,also Three 12cm Fans positions are reserved in the rear window

Expansion Slot

None Slots But Positions are built in for six Graphics

Panel Setting

Two USB2.0; One Power switch; One Reset switch; One Blue Power indicator; One Red Hard disk indicator

Case Material

Ma Steel flowers-free zinc plating

Material Thickness

1.0MM

Delivery time

1 Week for sample ,2 Weeks for mass goods

Payment Terms

30%TT Prepay 70%TT before shipment
